THE NEW BMW 3 SERIES SEDAN M AUTOMOBILES: ENGINES & TECHNICAL DATA.

THE M3THE NEW BMW 3 SERIES SEDAN M AUTOMOBILES: ENGINES & TECHNICAL DATA.

Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW M3 Competition Sedan.

Read more

BMW 3 SERIES SEDAN M AUTOMOBILES: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1,805
Max. permissible weight in kg 2,210
Permitted load in kg 480
Permitted axle load front/rear in kg 1,080/1,180
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 375 (510)/6,250
Engine torque (Nm) at 1/min 650/2,750-5,500
Compression ratio : 1 9.3

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 3.9

Fuel consumption

Combined in l/100 km 9.8
CO2 combined emissions in g/km 224-223
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 275/40 ZR18 (103Y) XL
Tyre dimensions rear 285/35 ZR19 (103Y) XL
Wheel dimensions and material front 9.5Jx18 inches, light-alloy
Wheel dimensions and material rear 10.5Jx19 inches, light-alloy

Weight

Unladen weight EU in kg 1.855
Max. permissible weight in kg 2,260
Permitted load in kg 480
Permitted axle load front/rear in kg 1,125/1,200
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 375 (510)/6,250
Engine torque (Nm) at 1/min 650/2,750-5,500
Compression ratio : 1 9.3

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 3.5

Fuel consumption

Combined in l/100 km 10.1-10.0
CO2 combined emissions in g/km 230-228
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 275/35 ZR19 (100Y) XL
Tyre dimensions rear 285/30 ZR20 (99Y) XL
Wheel dimensions and material front 9.5 J x 19 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 20 inches, light-alloy

Weight

Unladen weight EU in kg 1,780
Max. permissible weight in kg 2,210
Permitted load in kg 505
Permitted axle load front/rear in kg 1,080/1,180
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 353 (480)/6,250
Engine torque (Nm) at 1/min 550/2,650-6,130
Compression ratio : 1 9.3

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.2

Fuel consumption

Combined in l/100 km 10.2-10.0
CO2 combined emissions in g/km 231-227
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 275/40 ZR18 (103Y) XL
Tyre dimensions rear 285/35 ZR19 (103Y) XL
Wheel dimensions and material front 9.5Jx18 inches, light-alloy
Wheel dimensions and material rear 10.5Jx19 inches, light-alloy

Weight

Unladen weight EU in kg 1,800
Max. permissible weight in kg 2,260
Permitted load in kg 535
Permitted axle load front/rear in kg 1,115/1,230
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 275 (374)/5,500-6,500
Engine torque (Nm) at 1/min 500/1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.4

Fuel consumption

Combined in l/100 km 8.5-7.8
CO2 combined emissions in g/km 192-177
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Weight

Unladen weight EU in kg 1.875
Max. permissible weight in kg 2,340
Permitted load in kg 540
Permitted axle load front/rear in kg 1,155/1,260
Luggage capacity min. (seats up or roof down) in l 480
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 250 (340)/4,400
Engine torque (Nm) at 1/min 700/1,750-2,250
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.6

Fuel consumption

Combined in l/100 km 6.4-5.9
CO2 combined emissions in g/km 169-154
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Fuel consumption and CO2 emissions.

  • BMW M3 Competition Sedan with M xDrive:
    Fuel consumption in l/100 km (combined): 10.1-10.0
    CO2 emissions in g/km (combined): 230-228

    BMW M3 Competition Sedan:
    Fuel consumption in l/100 km (combined): 9.8
    CO2 emissions in g/km (combined): 224-223

    BMW M3 Sedan:
    Fuel consumption in l/100 km (combined): 10.2-10.0
    CO2 emissions in g/km (combined): 231-227

    BMW M340i xDrive Sedan:
    Fuel consumption in l/100 km (combined): 8.5-7.8
    CO2 emissions in g/km (combined): 192-177

    BMW M340d xDrive Sedan:
    Fuel consumption in l/100 km (combined): 6.4-5.9
    CO2 emissions in g/km (combined): 169-154

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/e10
