THE NEW BMW 3 SERIES TOURING M AUTOMOBILES: ENGINES & TECHNICAL DATA.

THE M3THE NEW BMW 3 SERIES TOURING M AUTOMOBILES: ENGINES & TECHNICAL DATA.
BMW 3 Series M Automobiles Touring: Overview

Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the new BMW 3 Series Touring M Automobiles.

Read more

ENGINES AND TECHNICAL DATA OF THE NEW BMW 3 SERIES TOURING M AUTOMOBILES.

Select model

Weight

Curb weight in kg [5] 1,940
Max. permissible weight in kg 2,370
Permitted load in kg 505
Permitted axle load front/rear in kg 1,125/1,275
Luggage capacity min. (seats up or roof down) in l 500
Luggage capacity max. (seats down or roof up) in l 1,510
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90/84
Engine power in kW (hp) at 1/min 375 (510)/5,510-7,200
Engine torque (Nm) at 1/min 650/2,750-5,500
Compression ratio : 1 9.3

Performance

Top speed in km/h 250 (280)
Acceleration 0–100 km/h in s 3.6

Fuel economy/emissions [1][2]

Combined in l/100 km 10.3
CO2 combined emissions in g/km 235
Tank capacity, approx. in l 59
Stationary noise level in dB(A)/1/min [3] -
Pass-by noise in dB(A) [3] -

Wheels

Tyre dimensions front 275/35-19
Tyre dimensions rear 285/30-20
Wheel dimensions and material front 9.5 J x 19 inches, light-alloy
Wheel dimensions and material rear 10.5 J x 20 inches, light-alloy

Weight

Curb weight in kg [5] 1,870
Max. permissible weight in kg 2,390
Permitted load in kg 595
Permitted axle load front/rear in kg 1,115/1,350
Luggage capacity min. (seats up or roof down) in l 500
Luggage capacity max. (seats down or roof up) in l 1,510
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 275 (374)/5,500-6,500
Engine torque (Nm) at 1/min 500/1,900-5,000
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.6

Fuel economy/emissions [1][2]

Combined in l/100 km 8.8-8.1
CO2 combined emissions in g/km 197-182
Tank capacity, approx. in l 59
Stationary noise level in dB(A)/1/min [3] - [3]
Pass-by noise in dB(A) [3] - [3]

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

Weight

Curb weight in kg [5] 1.945
Max. permissible weight in kg 2,430
Permitted load in kg 560
Permitted axle load front/rear in kg 1,160/1,360
Luggage capacity min. (seats up or roof down) in l 500
Luggage capacity max. (seats down or roof up) in l 1,510
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 250 (340)/4,400
Engine torque (Nm) at 1/min 700/1,750-2,250
Compression ratio : 1 16.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.7

Fuel economy/emissions [1][2]

Combined in l/100 km 6.6-6.0
CO2 combined emissions in g/km 173-157
Tank capacity, approx. in l 59
Stationary noise level in dB(A)/1/min [3] - [3]
Pass-by noise in dB(A) [3] - [3]

Wheels

Tyre dimensions front 225/45 R18 95 Y XL
Tyre dimensions rear 255/40 R18 99 Y XL
Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy
​

Fuel consumption and CO2 emissions.

  • BMW M3 Competition Touring:
    Fuel consumption in l/100 km (combined): 10.3
    CO2 emissions in g/km (combined): 235

    BMW M340i xDrive Touring:
    Fuel consumption in l/100 km (combined): 8.8-8.1
    CO2 emissions in g/km (combined): 197-182

    BMW M340d xDrive Touring:
    Fuel consumption in l/100 km (combined): 6.6-6.0
    CO2 emissions in g/km (combined): 173-157

    The dimensions in the technical drawing are preliminary values.
