BMW X1: TECHNICAL DATA.

Weight

Unladen weight EU in kg 1,480 [1,510]
Max. permissible weight in kg 2,000 [2,025]
Permitted load in kg 595 [590]
Permitted axle load front/rear in kg 995/1,035 [1,020/1,035]
Luggage capacity min. (seats up or roof down) in l 505 [505]
Luggage capacity max. (seats down or roof up) in l 1,550 [1,550]
Trailer load (unbraked) in kg 740 [750]
Trailer load 8% (braked) in kg 1,700 [1,700]
Trailer load 12% (braked) in kg 1,700 [1,700]

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 100 (136)/4,500-6,500
Engine torque (Nm) at 1/min 220/1,500-4,100
Compression ratio : 1 11.0

Performance

Top speed in km/h 205 [203]
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 9.7 [9.7]

Fuel consumption

Combined in l/100 km 7.2-6.1
CO2 combined emissions in g/km 163-139
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,655
Max. permissible weight in kg 2.155
Permitted load in kg 575
Permitted axle load front/rear in kg 1,090/1,100
Luggage capacity min. (seats up or roof down) in l 505
Luggage capacity max. (seats down or roof up) in l 1,550
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 131 (178)/5,000-5,500
Engine torque (Nm) at 1/min 280/1,350-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 223
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 7.3

Fuel consumption

Combined in l/100 km 7.7-6.9
CO2 combined emissions in g/km 175-158
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 61

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,570
Max. permissible weight in kg 2.065
Permitted load in kg 570
Permitted axle load front/rear in kg 1,050/1,050
Luggage capacity min. (seats up or roof down) in l 505
Luggage capacity max. (seats down or roof up) in l 1,550
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 131 (178)/5,000-5,500
Engine torque (Nm) at 1/min 280/1,350-4,200
Compression ratio : 1 11.0

Performance

Top speed in km/h 226
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 7.6

Fuel consumption

Combined in l/100 km 7.3-6.5
CO2 combined emissions in g/km 165-147
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,555 [1,575]
Max. permissible weight in kg 2,040 [2,040]
Permitted load in kg 560 [540]
Permitted axle load front/rear in kg 1,035/1,070 [1,065/1,070]
Luggage capacity min. (seats up or roof down) in l 505 [505]
Luggage capacity max. (seats down or roof up) in l 1,550 [1,550]
Trailer load (unbraked) in kg 750 [750]
Trailer load 8% (braked) in kg 1,700 [1,700]
Trailer load 12% (braked) in kg 1,700 [1,700]

Engine

Cylinders/valves 3/4
Capacity in ccm 1,496
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 85 (116)/4,000
Engine torque (Nm) at 1/min 270/1,750-2,250
Compression ratio : 1 16.5

Performance

Top speed in km/h 190 [190]
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 11.5 [11.5]

Fuel consumption

Combined in l/100 km 5.7-5.1
CO2 combined emissions in g/km 150-132
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,585 [1,615]
Max. permissible weight in kg 2,090 [2,125]
Permitted load in kg 580 [588]
Permitted axle load front/rear in kg 1,055/1,070 [1,095/1,070]
Luggage capacity min. (seats up or roof down) in l 505 [505]
Luggage capacity max. (seats down or roof up) in l 1,550 [1,550]
Trailer load (unbraked) in kg 750 [750]
Trailer load 8% (braked) in kg 1,800 [1,800]
Trailer load 12% (braked) in kg 1,800 [1,800]

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 100-110 (136-150)/4,000
Engine torque (Nm) at 1/min 350/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 200-205 [200-205]
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 10.0-9.3 [10.1-9.4]

Fuel consumption

Combined in l/100 km 5.8-4.9
CO2 combined emissions in g/km 151-128
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm

Weight

Unladen weight EU in kg 1.685
Max. permissible weight in kg 2,190
Permitted load in kg 580
Permitted axle load front/rear in kg 1,115/1,110
Luggage capacity min. (seats up or roof down) in l 505
Luggage capacity max. (seats down or roof up) in l 1,550
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 100-110 (136-150)/4,000
Engine torque (Nm) at 1/min 350/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 197-204
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 10.2-9.4

Fuel consumption

Combined in l/100 km 6.1-5.4
CO2 combined emissions in g/km 159-142
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,630
Max. permissible weight in kg 2,130
Permitted load in kg 575
Permitted axle load front/rear in kg 1,095/1,080
Luggage capacity min. (seats up or roof down) in l 505
Luggage capacity max. (seats down or roof up) in l 1,550
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 1,800
Trailer load 12% (braked) in kg 1,800

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 140 (190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 222
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 7,9

Fuel consumption

Combined in l/100 km 5.8-5.2
CO2 combined emissions in g/km 152-136
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,695
Max. permissible weight in kg 2,200
Permitted load in kg 580
Permitted axle load front/rear in kg 1,115/1,120
Luggage capacity min. (seats up or roof down) in l 505
Luggage capacity max. (seats down or roof up) in l 1,550
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 120-140 (163-190)/4,000
Engine torque (Nm) at 1/min 400/1,750-2,500
Compression ratio : 1 16.5

Performance

Top speed in km/h 211-219
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 8.7-7.8

Fuel consumption

Combined in l/100 km 6.3-5.4
CO2 combined emissions in g/km 164-142
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,695
Max. permissible weight in kg 2,180
Permitted load in kg 560
Permitted axle load front/rear in kg 1,125/1,095
Luggage capacity min. (seats up or roof down) in l 505
Luggage capacity max. (seats down or roof up) in l 1,550
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,000
Trailer load 12% (braked) in kg 2,000

Engine

Cylinders/valves 4/4
Capacity in ccm 1,995
Stroke/bore in mm 90.0/84.0
Engine power* in kW (hp) at 1/min 170 (231)/4,400
Engine torque (Nm) at 1/min 450/1,500-3,000
Compression ratio : 1 16.5

Performance

Top speed in km/h 235
Top speed electrical in km/h -
Acceleration 0–100 km/h in s 6.6

Fuel consumption

Combined in l/100 km 6.3-5.7
CO2 combined emissions in g/km 166-149
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 51

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

Range and charging

Electric range in km -
Growth capacity of lithium-ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Weight

Unladen weight EU in kg 1,820
Max. permissible weight in kg 2,330
Permitted load in kg 585
Permitted axle load front/rear in kg 1,110/1,270
Luggage capacity min. (seats up or roof down) in l 450
Luggage capacity max. (seats down or roof up) in l 1,470
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 750
Trailer load 12% (braked) in kg 750

Engine

Cylinders/valves 3/4
Capacity in ccm 1,499
Stroke/bore in mm 94.6/82.0
Engine power* in kW (hp) at 1/min 92 (125)/5,000-5,500
Engine torque (Nm) at 1/min 220/1,500-3,800
Compression ratio : 1 11.0

Performance

Top speed in km/h 193
Top speed electrical in km/h 135
Acceleration 0–100 km/h in s 6.9

Fuel consumption

Combined in l/100 km 2.1-1.7
CO2 combined emissions in g/km 47-39
Electricity consumption, combined in kWh/100km 15.7-15.0
Tank capacity, approx. in l 36

Wheels

Tyre dimensions front 225/55 R17 97 W
Tyre dimensions rear 225/55 R17 97 W
Wheel dimensions and material front 7,5 J x17 inches, light-alloy
Wheel dimensions and material rear 7,5 J x17 inches, light-alloy

Range and charging

Electric range in km 47-52
Growth capacity of lithium-ion battery in kWh 10
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h 2.4
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h 3.2

Electric engine

Electric engine power kW (hp) at 1/min 70 (95)/4,500
Electric Engine torque (Nm) at 1/min 165/100-3,000

Combined system power

Combined power kW (hp) 162 (220)
Combined torque Nm 385

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW X1 xDRIVE20i:
Fuel consumption in l/100 km (combined): 7.7–6.9
CO2 emissions in g/km (combined): 175–158

BMW X1 xDrive25e**:
Fuel consumption in l/100 km (combined): 1.9–1.7
CO2 emissions in g/km (combined): 44–39
Energy consumption in kWh/100 km (combined): 19.6–19.2


Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp


** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.

Read more

Fuel consumption and CO2 emissions.

  • BMW X1 xDrive20i:
    Fuel consumption in l/100 km (combined): 7.7-6.9
    CO2 emissions in g/km (combined): 175-158

    The values of the vehicles labeled with (2) are preliminary.

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tires available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html
